Features:
‧ Designed with horizontal chamber of large capacity
‧ Double wall chamber is made of thick stainless steel and is insulated by glass fiber and cover with stainless steel sheet.
‧ High pressure resistant stainless steel door with silicon rubber gasket, heavy duty hinge, stainless steel locking bars ensure pressure tight and light action for opening or closing chamber door by door head accommodated with thrust bearing.
‧ Unit is mounted on a heavy duty stand of tubular stainless steel with gunmetal floor flange chrome-plated for level adjustment.
‧ Integral steam generator of electric heating is installed with the autoclave on request. Immersion heater is protected from burning out by a low water control device.
‧ Automatic pressure controller is used for jacket and chamber pressure regulation and a safety valve is used to discharge the overloaded pressure.
‧ Automatic air and condensation venting device exhausts air and unsaturated steam from chamber to get the pure steam pressure.
‧ Drying cycle is available by the steam-heat from the jacket. A buzzer sounds on the compilation of the full cycle and the heating power cuts off automatically.
Optional accessory:
‧ Automatic feed water device
Safety devices:
‧ Door switch: Programs start only if door is properly locked.
‧ Safety valve: Releasing excess steam (if the pressure rises over 2 kg/cm).
‧ Low water protection device: The buzzer sounds and cuts off power in case of insufficient water levels.
‧ Circuit protection device: Fuse protects control units when short circuit or overload occurs.
‧ Emergency exhaust: Manual exhaust to vent the chamber and remove the load in the event of a power outage.
